產品型號 Model | 額定電壓 Rated Voltage (V) | 額定功率 Rated Power (W) | 空載轉速 No-load Speed (rpm) | 空載電流 No-load Current (A) | 負載轉速 Load Speed (rpm) | 負載電流 Load Current (A) | 負載力矩 Load Torque (N.m) | 減速比 Reduction Ratio | 鋼殼長度 Length (mm) |
| ZD63-1260-60 | 12 | 60 | 60±5 | ≤1.5 | 50±5 | ≤6 | ≥8 | 1:60 | 85 |
| ZD63-1280-160 | 12 | 80 | 160 | ≤1.6 | 140±10 | ≤7 | ≥3 | 1:24 | 85 |
| ZD63-2410-6 | 24 | 10 | 6±1 | ≤0.3 | 4±1 | ≤1.5 | ≥2 | 1:75 | 85 |
| ZD63-2415-15 | 24 | 15 | 15±2 | ≤0.5 | 12±2 | ≤2.0 | ≥4 | 1:75 | 85 |
| ZD63-2445-180 | 24 | 45 | 180 | ≤1.2 | 150±5 | ≤4.0 | ≥3.5 | 1:20 | 85 |
| ZD63-2480-320 | 24 | 80 | 320 | ≤1.8 | 250±25 | ≤6.0 | ≥6 | 1:15 | 85 |
| ZD63-2480-250 | 24 | 80 | 250 | ≤1.8 | 200±20 | ≤6.0 | ≥5 | 1:15 | 85 |
| ZD63-2480-160 | 24 | 80 | 160 | ≤1.2 | 140±10 | ≤5.0 | ≥4 | 1:24 | 85 |
| ZD63-2480-100 | 24 | 80 | 100 | ≤1.8 | 80±5 | ≤7.5 | ≥8 | 1:60 | 85 |
| ZD63-2480-50 | 24 | 80 | 50±5 | ≤1.2 | 45±5 | ≤4.5 | ≥6 | 1:60 | 85 |
| ZD63-2480-30 | 24 | 80 | 33±3 | ≤0.8 | 25±3 | ≤4.8 | ≤4.8 | 1:68 | 85 |
| ZD63-3680-40 | 36 | 80 | 40±5 | ≤1.0 | 32±3 | ≤4.0 | ≥6 | 1:60 | 85 |
| ZD63-4880-30 | 48 | 80 | 33±3 | ≤0.5 | 25±5 | ≤3.0 | ≥8 | 1:68 | 85 |
| ZD63-11080-60 | 110 | 80 | 60±6 | ≤0.3 | 52±5 | ≤1 | ≥8 | 1:60 | 85 |
| ZD63-2480-30 | 24 | 80 | 33±3 | ≤0.8 | 25±3 | ≤4.8 | ≥8 | 1:68 | 85 |
| ZD63-22080-400 | 220 | 80 | 400 | ≤0.4 | 320±40 | ≤0.8 | ≥6 | 1:15 | 85 |
| ZD63-22080-30 | 220 | 80 | 30±3 | ≤0.2 | 25±2 | ≤0.5 | ≥7 | 1:60 | 85 |
