產品型號 Model | 額定電壓 Rated Voltage (V) | 額定功率 Rated Power (W) | 空載轉速 No-load Speed (rpm) | 空載電流 No-load Current (A) | 負載轉速 Load Speed (rpm) | 負載電流 Load Current (A) | 負載力矩 Load Torque (N.m) | 減速比 Reduction Ratio | 鋼殼長度 Length (mm) |
| ZD76-220260-70 | 220 | 260 | 70±7 | ≤0.3 | 58±5 | ≤1.0 | ≥20 | 1:60 | 108 |
| ZD76-12120-50 | 12 | 120 | 50±5 | ≤1.5 | 38±5 | ≤8 | ≥8 | 1:75 | 97 |
| ZD76-2495-180 | 24 | 95 | 180±5 | ≤1.2 | 15±5 | ≤4.5 | ≥4.5 | 1:20 | 97 |
| ZD76-2495-150 | 24 | 95 | 150±5 | ≤1.0 | 130±5 | ≤3.5 | ≥3.3 | 1:20 | 97 |
| ZD76-24150-60 | 24 | 150 | 60±5 | ≤1.5 | 48±5 | ≤6.0 | ≥12 | 1:60 | 97 |
| ZD76-220200-60 | 200 | 200 | 60±5 | ≤0.2 | 45±5 | ≤0.8 | ≥15 | 1:60 | 97 |
| ZD76-2465-180 | 24 | 65 | 180±5 | ≤1.2 | 150±5 | ≤4.5 | ≥4.5 | 1:20 | 85 |
| ZD76-2465-210 | 24 | 65 | 210±5 | ≤1.5 | 180±5 | ≤6.5 | ≥6.0 | 1:20 | 85 |
| ZD76-24120-50 | 24 | 120 | 50±5 | ≤1.2 | 40±5 | ≤4.5 | ≥8 | 1:60 | 85 |
| ZD76-22065-180 | 220 | 65 | 180±5 | ≤0.2 | 150±5 | ≤0.5 | ≥4.5 | 1:20 | 85 |
| ZD76-2445-180 | 24 | 45 | 180±5 | ≤1.2 | 150±5 | ≤4.5 | ≥4.5 | 1:20 | 77 |
| ZD76-2445-210 | 24 | 45 | 210±5 | ≤1.5 | 180±5 | ≤6.5 | ≥6.0 | 1:20 | 77 |
